3M Scotchlok Block Fork, Vinyl Insulated Brazed Seam MV14-6FB/SK, StudSize 6

by 3M
No reviews
Original price $245.99 - Original price $245.99
Original price
$245.99
$245.99 - $245.99
Current price $245.99
Free shipping
3M Scotchlok Color-Coded Block Fork is a lug connection terminal that ensures an ideal fit while offering reliable and safe performance. The terminal has a vinyl-insulated, brazed-seam barrel and withstands temperatures of -40 to 221... Read more
This product is made to order. Please allow 8 days for production.

Overview

3M

3M Scotchlok Block Fork, Vinyl Insulated Brazed Seam MV14-6FB/SK, StudSize 6

3M Scotchlok Color-Coded Block Fork is a lug connection terminal that ensures an ideal fit while offering reliable and safe performance. The terminal has a vinyl-insulated, brazed-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.3M™ Scotchlok™ Block Fork Terminal is color-coded for quick and easy identification of the wire size required. It has a brazed-seam barrel that is covered by a funnel-designed, rigid-molded, polyvinyl chloride sleeve to guide the wire into position while providing electrical contacts and mechanical stress relief at the point of insulation. The abrasion-resistant, flared, vinyl-sleeve insulation ensures easy crimping. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
  • Vinyl-insulated, brazed-seam barrel ensures a secure fit and offers reliable performance
  • Funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires
  • Suitable for use in a terminal block

Product Details

General Information
Brand
Scotchlok™
Barrel Style
Brazed
Fork Type
Block
Terminal Style
Block
Terminal Type
Fork
Country Of Origin
United States
Lead Time
8 days
California Residents
Dimensions and Specifications
Barrel Inside Diameter
0.090 Inch
Barrel Length (Imperial)
0.25 Inch
Maximum Conductor Size (Imperial)
14 AWG
Maximum Conductor Size (Metric)
2.08 mm²
Maximum Insulation Outer Diameter (Imperial)
0.17 in
Minimum Conductor Size (Imperial)
16 AWG
Minimum Conductor Size (Metric)
1.31 mm²
Overall Length (Imperial)
0.85 in
Overall Width (Imperial)
0.25 in
Stud Diameter (Imperial)
0.138 in
Stud Diameter (Metric)
3.505 mm
Stud Size
#6
Barrel Length Imperial
0.25 Inch
Maximum Conductor Size Imperial
14 AWG
Maximum Conductor Size Metric
2.08 mm²
Minimum Conductor Size Imperial
16 AWG
Minimum Conductor Size Metric
1.31 mm²
Overall Length Imperial
0.85
Other Details
CSA File Number
LR22190
Clearance (C)
0.25 Inch
Dimension E
0.7 Inch
Solution For
Wireless Network: Infrastructure Accessories
UL File Number
E23438
Units Per Case
1000.0
Material and Composition
Insulation Material
Vinyl
Packaging and Shipping
Packaging
1000 per bulk box
