3M Scotchlok Male Disconnect

by 3M
No reviews
Original price $225.99 - Original price $225.99
Original price
$225.99
$225.99 - $225.99
Current price $225.99
Free shipping
3M Scotchlok Color-Coded Heat Shrink Male Disconnect Terminal allows for quick and easy disconnect. The butted-seam barrel is covered by an adhesive-lined polyolefin tubing to offer moisture-seal protection. It withstands a maximum temperature of 221... Read more
This product is made to order. Please allow 20 days for production.

Overview

3M

3M Scotchlok Male Disconnect

3M Scotchlok Color-Coded Heat Shrink Male Disconnect Terminal allows for quick and easy disconnect. The butted-seam barrel is covered by an adhesive-lined polyolefin tubing to offer moisture-seal protection. It withstands a maximum temperature of 221 degrees F (105 degrees C). Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.3M™ Scotchlok™ Color-Coded Heat Shrink Male Disconnect Terminal attaches to the mating part with a tongue that slips over the female tab. This versatile terminal has a butted-seam barrel that is covered by a see-through, pre-insulated transparent tubing. The tubing provides seal resistance to water, salt and other contaminants when crimped and shrunk. The heat shrink tubing offers better pullout strength and strain relief when shrunk. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
  • This male disconnect terminal offers excellent holding force
  • When crimped and shrunk, pre-insulated adhesive-lined polyolefin offers seal resistance to water and salt
  • Mates with 0.25-in wide female tab
  • Made of electrolytic copper for good conductivity and has corrosion-resistant tin plating
  • Withstands a maximum temperature of 221 degrees F (105 degrees C)
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant

Product Details

General Information
Brand
Scotchlok™
Barrel Style
Butted
Disconnect Type
Male
Terminal Style
Fully Insulated
Terminal Type
Disconnect
Country Of Origin
United States
Lead Time
20 days
California Residents
Dimensions and Specifications
Barrel Inside Diameter
0.15 Inch
Barrel Length (Imperial)
0.25 Inch
Connection Width (Imperial)
0.25 in
Connection Width (Metric)
6.35 mm
Diameter (D)
0.39 Inch
Male Tab Width (W')
0.25 Inch
Maximum Conductor Size (Imperial)
10 AWG
Maximum Conductor Size (Metric)
6 mm²
Minimum Conductor Size (Imperial)
12 AWG
Minimum Conductor Size (Metric)
4 mm²
Overall Diameter (Imperial)
0.39 in
Overall Length (Imperial)
1.2 in
Overall Width (Imperial)
0.47 in
Pad Width
0.25 in
Tab Width
0.250
Barrel Length Imperial
0.25 Inch
Conductor Sizes Imperial
12 - 10 AWG
Overall Length Imperial
1.2
Other Details
Fastener Orientation
Male
Units Per Case
250.0
Material and Composition
Insulation Material
Heat Shrink
Packaging and Shipping
Packaging
250 per bulk box
