Athena Power AP-MP4ATX30 APOLLO Micro ATX 300W replacement for E-machine, HP, Compaq, Gateway

No reviews
Original price $45.99 - Original price $45.99
Original price
$45.99
$45.99 - $45.99
Current price $45.99
Free shipping
The APOLLO 300Watt is the 2nd model released in Athena Power's Micro SFX series, it has increased overall performance and maintains its green efficient standard. Featuring a Smart Fan Speed Controller and with its reduced... Read more

Overview

Athena Power

Athena Power AP-MP4ATX30 APOLLO Micro ATX 300W replacement for E-machine, HP, Compaq, Gateway

The APOLLO 300Watt is the 2nd model released in Athena Power's Micro SFX series, it has increased overall performance and maintains its green efficient standard. Featuring a Smart Fan Speed Controller and with its reduced noise and ripple features, this power supply was designed especially for E-machine, HP, IBM, Compaq, and Gateway PCs. The Micro SFX Design Micro SFX power supplies are known mostly as a replacement power supply, but it has now evolved and can be used for mini-ATX cases, custom built computers, mini-servers, and more. With the increase of wattage and efficiency, the micro SFX is a conventional PSU that can be used for multiple purposes. Designed for custom built PCs, mini-servers, and HTPCs. The APOLLO 300 Watt power supply will support the most current ATX motherboards V2.2 and lower. Its PCI-E 6-pin connector supports an additional VGA card. This PSU is ideal for custom-built PCs, mini-servers, and HTPCs. Smart Auto Fan Speed Controller Thermal fan speed control it will detect the amount of heat generated by the computer. Using this controller to detect the heat levels, it will automatically adjust the fan speed accordingly and the need to worry about the heat levels, of a PSU, becomes almost non-existent.

Product Details

General Information
Manufacturer
Athena Power
Part Number
AP-MP4ATX30
Product Type
Power Supply
California Residents
Power Description
Input Voltage Type
AC
Input Voltage
88 ~ 264 Volts AC
Output Voltage
+5V@13A, -5V@0.5A, +12V1@14A, +12V2@14A, +3.3V@13A, -12V@0.5A, +5V_SB@2.5A
Output Power
300 Watts
Physical Characteristics
Height
2.4"
Width
5"
Weight (Approximate)
2 lbs
Interfaces Ports
Connectors
ATX Connector 24 (20+4) Pin x 1
P4-12V 4 Pin x 1
SATA 15 Pin x 2
Molex 4 Pin x 4
Floppy 4 Pin x 1
HP Video 4 Pin x 1
