This powerful power supply delivers 600 Watts true power to meet today's high-end system requirements. Silent and heat resistant dual fans with smart temperature and automatic fan speed control. It supports Core 2 Dual &... Read more

Overview

Athena Power

Athena Power AP-P4ATX60FEP8 True Green/Active PFC EPS/ATX-12V 600W 80 PLUS BRONZE

This powerful power supply delivers 600 Watts true power to meet today's high-end system requirements. Silent and heat resistant dual fans with smart temperature and automatic fan speed control. It supports Core 2 Dual & Quad Core Processors plus it's Nvidia SLI and Quad SLi compatible. This 600W power is for new, OEM, PC, server assemblies, MiniServers, rackmount servers, and also supports both 20- or 24-pin ATX v.2.2 & EPS-12V Xeon motherboards. The package includes four PCI Express 6pin / 8pin connectors for Multi-GPU graphic card, which can supply power to advanced Graphics cards that require Dual 6pin or 6+2 pin. ACTIVE PFC Auto switch is also built-in to the PSU and this power supply supports Intel® Skulltrail and Core i7 platform systems. Multiple Support Function Supporting ATX V2.3, EPS-12V Xeon, and i7 motherboards it also includes PCI-E 6 and 6+2 pin connectors for advanced graphics cards running in quad SLI or Crossfire configuration. This PSU can be used for mini-servers, server assemblies, rackmount servers, and desktops. Active PFC, Full Range, and You. The Active PFC and Full Range function provides a smarter PSU. Able to detect the differences of wattage that is needed to power up your system, you can be rest assured as it will provide and maintain the most suitable power needed. Dual Fan With its dual fan features located at the front and back of the power supply, the rear fan intakes the heat that is produced inside the server or system and pushes it through the front fan. This design allows the power supply to be able to take 100% of the heat that is generated by the interior system and pushes it out of the server/system. While some other PSU fans work differently, this dual fan design is targeted to maintain a reliable source of power and keeping the system cool. Some may second guess this dual fan feature because it will increase noise volumes, but with its thermal fan speed control it will detect the amount of heat generated by the computer and spin accordingly. Smart Auto Fan Speed Controller Thermal fan speed control will detect the amount of heat generated by the computer and spin accordingly. Using this controller to detect the heat levels, it will automatically adjust the fan speed accordingly and the need to worry about the heat leves,l of a PSU, becomes almost non-existent.

Product Details

General Information
Manufacturer
Athena Power
Part Number
AP-P4ATX60FEP8
Product Type
Power Supply
California Residents
Power Description
Input Voltage Type
AC
Input Voltage
88 ~ 264 Volts AC
Output Voltage
+5V@20A, +12V1@24A, +12V2@24A, -12V@1.0A, +3.3V@18A, +5V_SB@3.5A
Output Power
600 Watts
Physical Characteristics
Height
3.25"
Width
5.75"
Weight (Approximate)
8 lbs
Interfaces Ports
Connectors
ATX Connector 24 (20+4) Pin x 1
P4-12V 4 Pin x 1
EPS 12V 8 Pin x 1
PCIE 6 Pin x 2
PCIE 6+2 Pin x 2
SATA 15 Pin x 6
Molex 4 Pin x 2
Floppy 4 Pin x 1
