3M Thin-Wall Heat Shrink Tubing EPS-300, Adhesive-Lined, 11/2-48"-Black-5 Pcs

by 3M
Original price $275.99 - Original price $275.99
Original price
$275.99
$275.99 - $275.99
Current price $275.99
Free shipping
Conquer your automotive and marine electrical jobs with help from 3M EPS-300 Heat Shrink Tubing. It features an internal thermoplastic layer of adhesive that promotes full moisture lock out, and the polyolefin fabrication supports long-lasting... Read more
Please allow 2 days for production.

Overview

3M

3M Thin-Wall Heat Shrink Tubing EPS-300, Adhesive-Lined, 11/2-48"-Black-5 Pcs

Conquer your automotive and marine electrical jobs with help from 3M EPS-300 Heat Shrink Tubing. It features an internal thermoplastic layer of adhesive that promotes full moisture lock out, and the polyolefin fabrication supports long-lasting use. Flame retardant and strong, this tubing has a 3:1 shrink ratio that provides protection for components in 600V-rated installations.3M™ Heat Shrink Tubing EPS-300 is color coded for quick and easy identification of the wire. It provides a skintight fit and strain relief protection for electronic components, wire splices, wire bundles and harness breakouts. This flame retardant tubing has a heat shrinkable outer wall that is irradiation cross linked for abrasion resistance and helps to maintain the high flow as well as good adhesion characteristics. When the tubing cools down, it forms a permanent, water resistant barrier. It withstands a wide temperature range of 67 to 230 degrees F ( 55 to 110 degrees C). UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
  • Dual-wall construction provides abrasion resistance and moisture-seal protection
  • Offers the advantage of integral, adhesive-lined construction
  • Offers protection for automotive, truck, electronic components, wire splices, wire bundles and harness breakouts
  • Made of black flexible polyolefin
  • Withstands temperatures of -67 to 230 degrees F (-55 to 110 degrees C)
  • Flame-retardant tubing is rated for 600V applications

Product Details

General Information
Brand
3M™
Heat Shrink Type
Adhesive-Lined Polyolefin Heat Shrink Tubing
Tubing Type
Dual Wall (Adhesive Lined)
Country Of Origin
United States
Sold As
Case
Lead Time
2 days
California Residents
Dimensions and Specifications
Expanded Inner Diameter
1.5 in
Expanded Inner Diameter (Metric)
38.10 mm
Inner Diameter After Shrink (Imperial)
0.51 in
Inner Diameter After Shrink (Metric)
12.95 mm
Inner Diameter Before Shrink (Imperial)
1.5 in
Inner Diameter Before Shrink (Metric)
38.1 mm
Maximum Operating Temperature (Celsius)
150 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
300 Degree Fahrenheit
Operating Temperature (Celsius)
-55 °C to 110 °C
Operating Temperature (Fahrenheit)
-67 °F to 230 °F
Operating Temperature Range (Celsius)
-55 °C to 110 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Overall Length (Imperial)
48 in
Recovered Inner Diameter
0.5 in
Recovered Inner Diameter (Metric)
13 mm
Tensile Strength (Imperial)
2100 Pound-Force Per Square Inch
Operating Temperature Celsius
-55 °C to 110 °C
Overall Length Imperial
48.0
Width
3.38 in
8.57 cm
Height
3.38 in
8.57 cm
Length
51.13 in
129.86 cm
Volume
582.42 cubic inch
9544.09 cm3
Weight
36.8 oz
1043.26 g
Other Details
Elongation
450 %
Flame Retardant
Yes
Mil Spec
AMS-DTL-23053/5, Class 3
Minimum Expanded Tubing I. D.
1.5 in
Non-Corrosive
Yes
Shrink Ratio
3:1
Solution For
Access Network: FTTH/FTTB/CATV
UL File Number
E-157227
Units Per Case
5.0
Family
3M™ Heat Shrink EPS-300
Tensile Strength Imperial
2100 Pound-Force Per Square Inch
Material and Composition
Material
Polyolefin
Shelf Life
3600
Color and Appearance
Product Color
Black
Certifications and Standards
Agency Approvals
CSA, UL Recognized
Flammability Rating
UL 224 All Tubing Flame Test [jacket]
