Dimensions and Specifications
Conductor Sizes (Imperial)
12 AWG (Stranded)
Conductor Sizes (Metric)
4 mm² (Stranded)
Maximum Conductor Size (Imperial)
12 AWG (Stranded)
Maximum Conductor Size (Metric)
4 mm² (Stranded)
Maximum Insulation Diameter (Inside Port)
0.15 in
Maximum Insulation Diameter (Inside Port) (Metric)
3.8 mm
Maximum Insulation Diameter (Outside Port)
0.21 in
Maximum Insulation Diameter (Outside Port) (Metric)
5.3 mm
Maximum Operating Temperature (Celsius)
105 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
221 Degree Fahrenheit
Maximum Voltage Rating
600 V
Minimum Conductor Size (Imperial)
18 AWG
Minimum Conductor Size (Metric)
1 mm²
Conductor Sizes Imperial
18 AWG
12 AWG (Stranded)
Maximum Conductor Size Imperial
12 AWG (Stranded)
Maximum Conductor Size Metric
4
Minimum Conductor Size Imperial
18 AWG
Minimum Conductor Size Metric
1 mm²
