Dimensions and Specifications
Conductor Sizes (Imperial)
14 AWG (Stranded)
Conductor Sizes (Metric)
2.5 mm² (Stranded)
Maximum Conductor Size (Imperial)
16 AWG
Maximum Conductor Size (Metric)
1.5 mm²
Maximum Operating Temperature (Celsius)
105 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
221 Degree Fahrenheit
Maximum Recommended Voltage Rating
600 V
Minimum Conductor Size (Imperial)
18 AWG
Minimum Conductor Size (Metric)
1 mm²
Run Maximum Insulation Outer Diameter (Imperial)
0.145 in
Run Maximum Insulation Outer Diameter (Metric)
3.7 mm
Tap Maximum Insulation Outer Diameter (Imperial)
0.145 in
Tap Maximum Insulation Outer Diameter (Metric)
3.7 mm
Voltage Application
Low Voltage
Conductor Sizes Imperial
18 AWG
14 AWG (Stranded)
16 AWG
Maximum Conductor Size Imperial
16 AWG
14 AWG (Stranded)
Maximum Conductor Size Metric
1.5
Minimum Conductor Size Imperial
18 AWG
Minimum Conductor Size Metric
1 mm²
Width
11.06 in
28.1 cm
Height
2.01 in
5.1 cm
Length
12.01 in
30.5 cm
Volume
266.73 cubic inch
4370.96 cm3
Weight
57.6 oz
1632.93 g
