Dimensions and Specifications
Backing Thickness (Metric)
0.25 mm
Breaking Strength (Imperial)
20 lb/in
High Temperature Rating
176°F (80°C)
Installation Temperature Range
10–150°F (-12–65°C)
Low Temperature Rating
32°F (0°C)
Maximum Installation Temperature (Celsius)
65 Degree Celsius
Maximum Installation Temperature (Fahrenheit)
150 Degree Fahrenheit
Maximum Operating Temperature (Celsius)
80 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
176 Degree Fahrenheit
Minimum Operating Temperature (Celsius)
-48 Degree Celsius
Operating Temperature (Celsius)
Up to 80 °C
Operating Temperature Range (Celsius)
-48 °C to 80 °C
Operating Temperature Range (Fahrenheit)
-55 °F to 176° F
Overall Length (Imperial)
100 ft
Overall Length (Metric)
30.5 m
Overall Width (Imperial)
1 in
Overall Width (Metric)
25.4 mm
Service Temperature Range
-55–176°F (-48–80°C)
Tape Length (Metric)
30.5 m
Tape Thickness (Imperial)
10 mil
Tape Width (Metric)
25.4 mm
Total Tape Thickness Without Liner (Imperial)
10 mil
Total Tape Thickness Without Liner (Metric)
0.254 mm
Total Thickness
0.25 mm
Operating Temperature Celsius
Up to 80 °C
Overall Length Imperial
100.0
