Dimensions and Specifications
Cable Diameter Range
8,1 - 39,4 mm
Cable Outside Diameter Range
0.32 - 1.55 inch
Cable Outside Diameter Range (Metric)
8-39 mm
Marker Size
1.0 inch x 5.0 inch
Maximum Cable Diameter (Imperial)
1.55 in
Maximum Cable Diameter (Metric)
39.3 mm
Maximum Cable Outside Diameter
0.32 - 1.55 Inch
Maximum Insulation Outer Diameter (Metric)
3.7 mm
Maximum Insulation Outside Diameter
0.145 in
Maximum Operating Temperature (Celsius)
49 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
120 Degree Fahrenheit
Maximum Outside Diameter
1.55 in (39.3 mm)
Maximum Recommended Voltage Rating
600 V
Minimum Cable Diameter (Imperial)
0.32 in
Minimum Cable Diameter (Metric)
8 mm
Operating Temperature Range (Celsius)
-40 °C to 121 °C
Overall Width (Metric)
25 mm
Write-on Area Size (Imperial)
1.0 inch x 1.0 inch
Write-on Area Size (Metric)
25.4 x 25.4 mm
Maximum Insulation Outer Diameter Metric
3.7
