Dimensions and Specifications
Conductor Sizes (Imperial)
16 AWG
Insulation Outside Diameter Range
1.25 - 3.25 Inch
Insulation Outside Diameter Range (Metric)
31.8-82.6 mm
Maximum Conductor Size (Imperial)
10 AWG
Maximum Conductor Size (Metric)
6 mm²
Maximum Insulation Outer Diameter (Imperial)
2.25 in
Maximum Insulation Outer Diameter (Metric)
57.2 mm
Minimum Conductor Size (Imperial)
22 AWG
Minimum Conductor Size (Metric)
.34 mm²
Minimum Insulation Outer Diameter (Imperial)
1.25 in
Minimum Insulation Outer Diameter (Metric)
31.8 mm
Molded Body Length
25 in
Molded Body Length (Metric)
635.0 mm
Voltage
1 kV
Maximum Conductor Size Imperial
10 AWG
Maximum Conductor Size Metric
6 mm²
Maximum Insulation Outer Diameter Metric
57.2
Minimum Conductor Size Imperial
22 AWG
Minimum Conductor Size Metric
.34 mm²
